Specifications
General
| Frequency range | Tx | 156.025–157.425 MHz |
|---|---|---|
| Rx | 156.050–163.275 MHz | |
| Rx (CH70) | 156.525 MHz | |
| RX (AIS) | 162.025 MHz | |
| Usable channel groups | INT, USA, CAN, WX channels | |
| Type of emission | 16K0G3E (FM), 16K0G2B (DSC), 16K0GXW (GMSK) | |
| Current drain (at 7.2 V DC) |
TX (6 W/1 W output) | 1500 mA/700 mA (approx.) |
| RX (Inter SP/Exter SP Max. audio) | 700 mA/350 mA (approx.) | |
| Operating temperature range | –20°C to +60°C; –4˚F to +140˚F | |
| Antenna impedance | 50 Ω | |
| Dimensions (W×H×D) (Projections not included) |
60.9 × 145.8 × 43.8 mm; 2.4 × 5.7 × 1.7 in |
|
| Weight (approximately) | 357 g ; 12.6 oz (With BP-306, antenna, MB-133) |
|
Transmitter
| Output power (Hi/Low) | 6 W/1 W | |
|---|---|---|
| Max. frequency deviation | ±5 kHz | |
| Frequency stability | ±10 ppm | |
| Spurious emissions | –68 dBc typical | |
Receiver
| Sensitivity (at 12 dB SINAD) DSC receiver (at 1% BER) AIS receiver (at 20% PER) |
0.25 μV typical –3 dBμ emf typical –107 dBm |
|
|---|---|---|
| Squelch sensitivity (Threshold) | 0.25 μV typical | |
| Adjacent channel selectivity DSC receiver (at 1% BER) AIS receiver (at 20% PER) |
70 dB typical 73 dBμ emf 50 dB typical |
|
| Spurious response DSC receiver (at 1% BER) AIS receiver (at 20% PER) |
70 dB typical 73 dBμ emf 50 dB typical |
|
| Intermodulation DSC receiver (at 1% BER) AIS receiver (at 20% PER) |
70 dB typical 68 dBμ emf 50 dB typical |
|
| Hum and noise | 40 dB | |
| Audio output power (at 10% distortion) |
Internal SP | 1500 mW typical (8 Ω load) |
| External SP | 350 mW typical (8 Ω load) | |
Measurements made in accordance with TIA/EIA-603. All stated specifications are subject to change without notice or obligation.
Applicable U.S. Military Specifications & IP Rating
| Standard |
MIL-810 G | |
|---|---|---|
| Method | Procedure | |
| Low Pressure |
500.5 |
I, II |
| High Temperature |
501.5 |
I, II |
| Low Temperature |
502.5 |
I, II |
| Temperature Shock |
503.5 |
I-C |
| Solar Radiation |
505.5 |
I |
| Rain Blowing/Drip |
506.5 |
I, III |
| Humidity |
507.5 |
II |
| Salt Fog |
509.5 |
- |
| Dust Blowing |
510.5 |
I |
| Immersion |
512.5 |
I |
| Vibration |
514.6 |
I |
| Shock |
516.6 |
I, IV |
Also meets equivalent MIL-STD-810-C, -D, -E and -F.
| Ingress Protection Standards | |
|---|---|
| Water |
IPX7 (Waterproof protection) |
All stated specifications are subject to change without notice or obligation.
Supplied Accessories
- BP-306 battery pack
- BC-251 battery charger
- AC adapter*
- CP-26 cigarette lighter cable
- MB-133 belt clip
- Antenna
- Hand strap
* May differ depending on version
